TRUFAST ROOF APPLICATIONS
Wood
Wood roof decking for commercial applications is commonly constructed from plywood or OSB (oriented strand board) due to its cost-effectiveness and wide availability. The suitability of wood decking depends on several factors, including roof slope, local building code requirements, and the specific performance needs of the roofing system. Decking materials should be air-dried or kiln-dried and free of defects such as cracks or knotholes. Additionally, appropriate fire ratings must be verified to ensure compliance with applicable codes. TRUFAST offers a broad range of precision-engineered fasteners designed to securely attach a variety of roofing system components to wood roof decks.
RECOMMENDED ATTACHMENT SOLUTIONS
#12 DP Roofing Fasteners
- Specifically engineered to secure insulation, coverboards, and base sheets to corrugate steel (16-22 ga.) and wood substrates
- #2 double flute self-drilling point and exclusive tapered entry thread design for quick steel penetration and exceptional back-out resistance
- 8 lengths from 1-5/8” to 8”
- Pairs with 3” Metal Insulation Plates or 3” Recessed Metal Insulation Plates depending on the application
- #12 DP Roofing Fasteners product page
Pre-Assembled #12 DP Phillips Truss Head Fastener & 3” Galvalume Insulation Plate
- Fasteners come pre-assembled to increase productivity of attaching insulation to metal and wood roof decks
- Available with specially designed stand-up tools and accessories for fastener placement and attachment
- #3 Phillips Truss Head (PA) style
- 8 lengths from 1-5/8” to 8”
- Pre-Assembled #12 DP Phillips Truss Head Fastener & 3” Galvalume Insulation Plate product page
#14 HD Roofing Fasteners
- Engineered to secure insulation, coverboards, base sheets and single-ply roof membrane systems to corrugated steel (16-22 ga.), wood, and concrete substrates
- #2 double flute self-drilling point and exclusive tapered entry thread design for quick steel penetration and exceptional back-out resistance
- 17 lengths from 1-1/4” to 12”
- Pairs with 3” Metal Insulation Plates, 3” Recessed Metal Insulation Plates, or Induction Weld Plates depending on the application
- #14 HD Roofing Fasteners product page
#14 HD Bi-Metal Stainless Steel Roofing Fasteners
- Made of 316 austenitic stainless steel alloy with hardened carbon steel drill point
- Engineered to secure insulation, coverboards, base sheets and single-ply roof membrane systems to corrugated steel (18-24 ga.) and wood substrates
- #2 double flute self-drilling point and exclusive tapered entry thread design for quick steel penetration and exceptional back-out resistance
- 10 lengths from 1-1/2” to 12”
- Pairs with 3” Metal Insulation Plates, 3” Recessed Metal Insulation Plates, or Induction Weld Plates depending on the application
- #14 HD Bi-Metal Stainless Steel Roofing Fasteners product page
#15 EHD Roofing Fasteners
- Engineered for lap attachment to corrugated steel (18-22 ga.) and wood substrates in higher wind uplift roof assemblies
- #2 double flute self-drilling point and exclusive tapered entry thread design for quick steel penetration and exceptional back-out resistance
- 17 lenghts from 2” to 24”
- Pairs with 3” Metal Insulation Plates, 3” Recessed Metal Insulation Plates, or Induction Weld Plates depending on the application
- #15 EHD Roofing Fasteners product page
